BN310P
Lighting plays a different role in every application
List the order codes — we prepare a quotation and check availability. · 37 order codes
Lighting plays a different role in every application. Some require latest-generation solutions with high light quality and connectivity; others just simple functionality. But whether for retail or industrial applications, you always need a combination of quality, performance, and flexibility. Get to know SlimPerformance. The Batten LED luminaire where all these benefits come together. Putting the new lighting trend in your company.
Every version of the family from the official catalogue. Click PDF to download the datasheet of a specific order code.
| Order code | Name | Luminous flux | Wattage | CCT | IP | Optic | |
|---|---|---|---|---|---|---|---|
| 919406022541 | BN310P G2 LED185/840 PSU MB L17W SlimPerform Batten G2, 102 W, 18500 lm, 4000 K | 18,500 lm | 102 W | 4000 | IP20 | — | |
| 919406022561 | BN310P G2 LED185/840 DIA MB L17W SlimPerform Batten G2, 102 W, 18500 lm, 4000 K | 18,500 lm | 102 W | 4000 | IP20 | — | |
| 919406022601 | BN310P G2 LED240/840 PSU MB L17W SlimPerform Batten G2, 146 W, 24200 lm, 4000 K | 24,200 lm | 146 W | 4000 | IP20 | — | |
| 919406022611 | BN310P G2 LED240/840 PSU WB L17W SlimPerform Batten G2, 146 W, 24200 lm, 4000 K | 24,200 lm | 146 W | 4000 | IP20 | — | |
| 919406022621 | BN310P G2 LED240/840 DIA MB L17W SlimPerform Batten G2, 146 W, 24200 lm, 4000 K | 24,200 lm | 146 W | 4000 | IP20 | — | |
| 919406022631 | BN310P G2 LED240/840 DIA WB L17W SlimPerform Batten G2, 146 W, 24200 lm, 4000 K | 24,200 lm | 146 W | 4000 | IP20 | — | |
| 919406022661 | BN310P G2 LED185/850 PSU MB L17W SlimPerform Batten G2, 102 W, 18500 lm, 5000 K | 18,500 lm | 102 W | 5000 | IP20 | — | |
| 919406022681 | BN310P G2 LED185/850 DIA MB L17W SlimPerform Batten G2, 102 W, 18500 lm, 5000 K | 18,500 lm | 102 W | 5000 | IP20 | — | |
| 919406022721 | BN310P G2 LED240/850 PSU MB L17W SlimPerform Batten G2, 146 W, 24200 lm, 5000 K | 24,200 lm | 146 W | 5000 | IP20 | — | |
| 919406022731 | BN310P G2 LED240/850 PSU WB L17W SlimPerform Batten G2, 146 W, 24200 lm, 5000 K | 24,200 lm | 146 W | 5000 | IP20 | — | |
| 919406022741 | BN310P G2 LED240/850 DIA MB L17W SlimPerform Batten G2, 146 W, 24200 lm, 5000 K | 24,200 lm | 146 W | 5000 | IP20 | — | |
| 919406022751 | BN310P G2 LED240/850 DIA WB L17W SlimPerform Batten G2, 146 W, 24200 lm, 5000 K | 24,200 lm | 146 W | 5000 | IP20 | — | |
| 919406022781 | BN310P G2 LED54/840 PSU MB L12W SlimPerform Batten G2, 29 W, 5400 lm, 4000 K | 5,400 lm | 29 W | 4000 | IP20 | — | |
| 919406022801 | BN310P G2 LED54/840 DIA MB L12W SlimPerform Batten G2, 29 W, 5400 lm, 4000 K | 5,400 lm | 29 W | 4000 | IP20 | — | |
| 919406022841 | BN310P G2 LED68/840 PSU MB L12W SlimPerform Batten G2, 36 W, 6800 lm, 4000 K | 6,800 lm | 36 W | 4000 | IP20 | — | |
| 919406022861 | BN310P G2 LED68/840 DIA MB L12W SlimPerform Batten G2, 36 W, 6800 lm, 4000 K | 6,800 lm | 36 W | 4000 | IP20 | — | |
| 919406022901 | BN310P G2 LED94/840 PSU MB L12W SlimPerform Batten G2, 51 W, 9400 lm, 4000 K | 9,400 lm | 51 W | 4000 | IP20 | — | |
| 919406022921 | BN310P G2 LED94/840 DIA MB L12W SlimPerform Batten G2, 51 W, 9400 lm, 4000 K | 9,400 lm | 51 W | 4000 | IP20 | — | |
| 919406022941 | BN310P G2 LED94/840 WIA MB L12W SlimPerform Batten G2, 51 W, 9400 lm, 4000 K | 9,400 lm | 51 W | 4000 | IP20 | — | |
| 919406022981 | BN310P G2 LED125/840 PSU MB L12W SlimPerform Batten G2, 70 W, 12500 lm, 4000 K | 12,500 lm | 70 W | 4000 | IP20 | — | |
| 919406023001 | BN310P G2 LED125/840 DIA MB L12W SlimPerform Batten G2, 70 W, 12500 lm, 4000 K | 12,500 lm | 70 W | 4000 | IP20 | — | |
| 919406023021 | BN310P G2 LED160/840 PSU MB L12W SlimPerform Batten G2, 95 W, 16000 lm, 4000 K | 16,000 lm | 95 W | 4000 | IP20 | — | |
| 919406023031 | BN310P G2 LED160/840 PSU WB L12W SlimPerform Batten G2, 95 W, 16000 lm, 4000 K | 16,000 lm | 95 W | 4000 | IP20 | — | |
| 919406023041 | BN310P G2 LED160/840 DIA MB L12W SlimPerform Batten G2, 95 W, 16000 lm, 4000 K | 16,000 lm | 95 W | 4000 | IP20 | — | |
| 919406023051 | BN310P G2 LED160/840 DIA WB L12W SlimPerform Batten G2, 95 W, 16000 lm, 4000 K | 16,000 lm | 95 W | 4000 | IP20 | — | |
| 919406023061 | BN310P G2 LED54/850 PSU MB L12W SlimPerform Batten G2, 29 W, 5400 lm, 5000 K | 5,400 lm | 29 W | 5000 | IP20 | — | |
| 919406023081 | BN310P G2 LED54/850 DIA MB L12W SlimPerform Batten G2, 29 W, 5400 lm, 5000 K | 5,400 lm | 29 W | 5000 | IP20 | — | |
| 919406023121 | BN310P G2 LED68/850 PSU MB L12W SlimPerform Batten G2, 36 W, 6800 lm, 5000 K | 6,800 lm | 36 W | 5000 | IP20 | — | |
| 919406023141 | BN310P G2 LED68/850 DIA MB L12W SlimPerform Batten G2, 36 W, 6800 lm, 5000 K | 6,800 lm | 36 W | 5000 | IP20 | — | |
| 919406023181 | BN310P G2 LED94/850 PSU MB L12W SlimPerform Batten G2, 51 W, 9400 lm, 5000 K | 9,400 lm | 51 W | 5000 | IP20 | — | |
| 919406023201 | BN310P G2 LED94/850 DIA MB L12W SlimPerform Batten G2, 51 W, 9400 lm, 5000 K | 9,400 lm | 51 W | 5000 | IP20 | — | |
| 919406023261 | BN310P G2 LED125/850 PSU MB L12W SlimPerform Batten G2, 70 W, 12500 lm, 5000 K | 12,500 lm | 70 W | 5000 | IP20 | — | |
| 919406023281 | BN310P G2 LED125/850 DIA MB L12W SlimPerform Batten G2, 70 W, 12500 lm, 5000 K | 12,500 lm | 70 W | 5000 | IP20 | — | |
| 919406023301 | BN310P G2 LED160/850 PSU MB L12W SlimPerform Batten G2, 95 W, 16000 lm, 5000 K | 16,000 lm | 95 W | 5000 | IP20 | — | |
| 919406023311 | BN310P G2 LED160/850 PSU WB L12W SlimPerform Batten G2, 95 W, 16000 lm, 5000 K | 16,000 lm | 95 W | 5000 | IP20 | — | |
| 919406023321 | BN310P G2 LED160/850 DIA MB L12W SlimPerform Batten G2, 95 W, 16000 lm, 5000 K | 16,000 lm | 95 W | 5000 | IP20 | — | |
| 919406023331 | BN310P G2 LED160/850 DIA WB L12W SlimPerform Batten G2, 95 W, 16000 lm, 5000 K | 16,000 lm | 95 W | 5000 | IP20 | — |
919406022541
BN310P G2 LED185/840 PSU MB L17W
919406022561
BN310P G2 LED185/840 DIA MB L17W
919406022601
BN310P G2 LED240/840 PSU MB L17W
919406022611
BN310P G2 LED240/840 PSU WB L17W
919406022621
BN310P G2 LED240/840 DIA MB L17W
919406022631
BN310P G2 LED240/840 DIA WB L17W
919406022661
BN310P G2 LED185/850 PSU MB L17W
919406022681
BN310P G2 LED185/850 DIA MB L17W
919406022721
BN310P G2 LED240/850 PSU MB L17W
919406022731
BN310P G2 LED240/850 PSU WB L17W
919406022741
BN310P G2 LED240/850 DIA MB L17W
919406022751
BN310P G2 LED240/850 DIA WB L17W
919406022781
BN310P G2 LED54/840 PSU MB L12W
919406022801
BN310P G2 LED54/840 DIA MB L12W
919406022841
BN310P G2 LED68/840 PSU MB L12W
919406022861
BN310P G2 LED68/840 DIA MB L12W
919406022901
BN310P G2 LED94/840 PSU MB L12W
919406022921
BN310P G2 LED94/840 DIA MB L12W
919406022941
BN310P G2 LED94/840 WIA MB L12W
919406022981
BN310P G2 LED125/840 PSU MB L12W
919406023001
BN310P G2 LED125/840 DIA MB L12W
919406023021
BN310P G2 LED160/840 PSU MB L12W
919406023031
BN310P G2 LED160/840 PSU WB L12W
919406023041
BN310P G2 LED160/840 DIA MB L12W
919406023051
BN310P G2 LED160/840 DIA WB L12W
919406023061
BN310P G2 LED54/850 PSU MB L12W
919406023081
BN310P G2 LED54/850 DIA MB L12W
919406023121
BN310P G2 LED68/850 PSU MB L12W
919406023141
BN310P G2 LED68/850 DIA MB L12W
919406023181
BN310P G2 LED94/850 PSU MB L12W
919406023201
BN310P G2 LED94/850 DIA MB L12W
919406023261
BN310P G2 LED125/850 PSU MB L12W
919406023281
BN310P G2 LED125/850 DIA MB L12W
919406023301
BN310P G2 LED160/850 PSU MB L12W
919406023311
BN310P G2 LED160/850 PSU WB L12W
919406023321
BN310P G2 LED160/850 DIA MB L12W
919406023331
BN310P G2 LED160/850 DIA WB L12W
