Office lightingDownlights
LuxSpace Pro
DN596B / DN591B / DN591X
Philips LuxSpace Pro builds on the LuxSpace family’s reputation for superb performance, extremely low energy use, high visual comfort and appearance design
List the order codes — we prepare a quotation and check availability. · 177 order codes
Family specifications
Ranges across every order code of the family. The exact values of a specific order code are in the table below: the «Specifications» button in its row.
Light technical
Luminous flux (lm)
420–8,170 lm
Efficacy (lm/W)
96–177 lm/W
CCT (K)
3000 / 4000 / Tunable white 2700-6500
Light distribution
High-efficiency reflector medium beam / Beam angle 60 to 120° / Wide beam angle 60° / High-reflective metal reflector Wide beam 40 to 80 degrees +1
UGR value
13 / 16 / 19 / 20 +10
Optical cover
Polycarbonate Diffuser
Electrical and controls
Wattage (W)
4.1–61.6 W
Dimming controls
DALI / Wireless / Fixed Output
Mechanical and housing
Housing material
Aluminum Alloy
Color of Housing
White
IP rating
IP20 / IP20(IP65 front)
IK rating
IK03 / IK03
Height (mm)
68–125 mm
Philips LuxSpace Pro builds on the LuxSpace family’s reputation for superb performance, extremely low energy use, high visual comfort and appearance design. This next generation of reliable LED downlights comes in an elegant design with a deep, recessed architecture and increased reflector depth to highlight the smallest of details. LuxSpace Pro is also a shining example of versatility. This energy-saving LED downlight is available in a comprehensive range of configurations from 450 to 8,000 lumen, 3inch to 8inch, with the option to choose fixed, dimmable, or Interact Ready variants. This makes LuxSpace Pro the perfect ‘mix and match’ solution for potentially broad and extended applications that require different lighting ambiances, with one cohesive luminaire look and feel.
Features
Best-in-class efficacy with up to 170lm/W
Deep recessed architecture with increased reflector depth
Spacious installation area with improved narrow rim width
Choice of multiple optics: Facetted, matt and white
75,000 hours lifetime @L70/B50 Ta 25°C
50,000 hours lifetime @L80/B10 Ta 25°C
DALI and wireless Interact compatible
Benefits
Energy-efficient LED
Creates a gentle, natural light, ensuring visual comfort
Perfect ceiling integration with narrow rim
Option of glossy facetted & matte clear aluminized (UGR19), or facetted & matte white reflector
Durable LED quality and reliability
Supports Human Centric Lighting with Tunable White and integrated lighting controls
