PowerBalance gen2
RC461B / RC463B / RC468B
When it comes to lighting office spaces with LED luminaires, businesses are willing to invest in sustainability, provided they get a payback on their investment
Luminous flux (lm)
2,800–8,000 lm
Wattage (W)
16–64 W
Efficacy (lm/W)
122–174 lm/W
CCT (K)
3000 / 4000 / Tunable white 2700-5000 / Tunable white 2700-6500
List the order codes — we prepare a quotation and check availability. · 139 order codes
Family specifications
Ranges across every order code of the family. The exact values of a specific order code are in the table below: the «Specifications» button in its row.
Light technical
Luminous flux (lm)
2,800–8,000 lm
Efficacy (lm/W)
122–174 lm/W
CCT (K)
3000 / 4000 / Tunable white 2700-5000 / Tunable white 2700-6500
DC operated central emergency lighting / Emergency lighting 3 hours duration with DALI interface
Mechanical and housing
Housing material
Steel
Color of Housing
White
IP rating
IP20/40
IK rating
IK03
Length (mm)
597–1,247 mm
Width (mm)
297–672 mm
Height (mm)
72–95 mm
When it comes to lighting office spaces with LED luminaires, businesses are willing to invest in sustainability, provided they get a payback on their investment. At the same time, the system should comply with office lighting norms to ensure a comfortable working environment. Philips PowerBalance Gen2 is our most energy-efficient, office-compliant LED luminaire. Designed for circularity and enhanced wellbeing, this office luminaire also promises future-proof connectivity. State-of-the-art efficacy (at CRI >90), upgradability features, a long lifetime, repairability, and design for recyclability make PowerBalance Gen2 a true ‘green choice’. One that also delivers significantly lower operational costs to ensure an attractive payback that meets the needs of businesses and the specification market.The Gen2 architecture in the latest PowerBalance range has enabled us to create a range of highly-versatile modular and semi-modular luminaires. These LED luminaires can be easily mounted in ceilings with an exposed T-bar or concealed T-bar, as well as plaster ceilings and bandraster-type ceilings. PowerBalance is a solution with superior lighting specifications combined with a best-in-class connectivity designed for Circularity & enhanced Wellbeing using Interact Pro - all with a sustainable approach to high-performance office lighting.
Features
Best-in-class efficacy up to 174lm/W supports green building design and energy saving subsidy criteria
3000K, 4000K, Tunable White options with CRI >90
Long lifetime 50,000 hours @L90
Prepared for circularity (no glue, replaceable electronics, upgradable system, efficient and long lifetime)
Environmental Product Declaration (EPD) guide
Connected system ready with Interact Pro scalable platform using integrated sensors and/or wireless drivers for data collection, occupancy, daylight regulation and wayfinding
Safety and installation: The product is IP20 and, as such, is not protected against water ingress. Therefore we strongly recommend that the environment in which the luminaire is to be installed should be suitably checked If the advice above is not taken and the luminaires are subject to water ingress, Philips / Signify cannot guarantee safe failure and the product warranty will become void
Benefits
Extremely-efficient LED luminaire with upto 174 lm/W
Complies with office norms
Comfortable, glare-free light
Significantly reduces operational costs for an attractive payback time
