SP780 / SP780X
The PureLine Slim family of luminaires gives you compromise-free office illumination
List the order codes — we prepare a quotation and check availability. · 99 order codes
The PureLine Slim family of luminaires gives you compromise-free office illumination. It is a perfect solution for office application and general indoor area lighting with Sleek profile which helps Declutter the ceilings. The range brings together high-flux lighting with a homogeneous optical system without making any concessions on energy efficiency design.
Every version of the family from the official catalogue. Click PDF to download the datasheet of a specific order code.
| Order code | Name | Luminous flux | Wattage | CCT | IP | Optic | |
|---|---|---|---|---|---|---|---|
| 919515815225 | SP780 H LED25S-6500 PSU W5L112 OD WH | 2,500 lm | 20 W | 6500 | IP20 | - | |
| 919515815226 | SP780 H LED25S-4000 PSU W5L112 OD WH | 2,500 lm | 20 W | 4000 | IP20 | - | |
| 919515815227 | SP780 H LED23S-6500 PSU W5L112 OC WH | 2,300 lm | 20 W | 6500 | IP20 | - | |
| 919515815228 | SP780 H LED23S-4000 PSU W5L112 OC WH | 2,300 lm | 20 W | 4000 | IP20 | - | |
| 919515815252 | SP780 H LED22S-6500 PSU W5L112 OD WH | 2,200 lm | 18 W | 6500 | IP20 | - | |
| 919515815253 | SP780 H LED22S-4000 PSU W5L112 OD WH | 2,200 lm | 18 W | 4000 | IP20 | - | |
| 919515815254 | SP780X H LED22S-6500 PSU W5L112 OD WH | 2,200 lm | 18 W | 6500 | IP20 | - | |
| 919515815255 | SP780X H LED22S-4000 PSU W5L112 OD WH | 2,200 lm | 18 W | 4000 | IP20 | - | |
| 919515815256 | SP780X H LED20S-6500 PSU W5L112 OC WH | 2,000 lm | 18 W | 6500 | IP20 | - | |
| 919515815257 | SP780X H LED20S-4000 PSU W5L112 OC WH | 2,000 lm | 18 W | 4000 | IP20 | - | |
| 919515815258 | SP780 H LED18S-6500 PSU W5L112 OD WH | 1,800 lm | 15 W | 6500 | IP20 | - | |
| 919515815259 | SP780 H LED18S-4000 PSU W5L112 OD WH | 1,800 lm | 15 W | 4000 | IP20 | - | |
| 919515815260 | SP780X H LED18S-6500 PSU W5L112 OD WH | 1,800 lm | 15 W | 6500 | IP20 | - | |
| 919515815261 | SP780X H LED18S-4000 PSU W5L112 OD WH | 1,800 lm | 15 W | 4000 | IP20 | - | |
| 919515815262 | SP780 H LED25S-6500 PSD W5L112 OD WH | 2,500 lm | 20 W | 6500 | IP20 | - | |
| 919515815263 | SP780 H LED25S-4000 PSD W5L112 OD WH | 2,500 lm | 20 W | 4000 | IP20 | - | |
| 919515815264 | SP780 H LED23S-6500 PSD W5L112 OC WH | 2,300 lm | 20 W | 6500 | IP20 | - | |
| 919515815265 | SP780 H LED23S-4000 PSD W5L112 OC WH | 2,300 lm | 20 W | 4000 | IP20 | - | |
| 919515815266 | SP780 H LED22S-6500 PSD W5L112 OD WH | 2,200 lm | 18 W | 6500 | IP20 | - | |
| 919515815267 | SP780 H LED22S-4000 PSD W5L112 OD WH | 2,200 lm | 18 W | 4000 | IP20 | - | |
| 919515815268 | SP780X H LED22S-6500 PSD W5L112 OD WH | 2,200 lm | 18 W | 6500 | IP20 | - | |
| 919515815269 | SP780X H LED22S-4000 PSD W5L112 OD WH | 2,200 lm | 18 W | 4000 | IP20 | - | |
| 919515815270 | SP780X H LED20S-6500 PSD W5L112 OC WH | 2,000 lm | 18 W | 6500 | IP20 | - | |
| 919515815271 | SP780X H LED20S-4000 PSD W5L112 OC WH | 2,000 lm | 18 W | 4000 | IP20 | - | |
| 919515815272 | SP780 H LED18S-6500 PSD W5L112 OD WH | 1,800 lm | 15 W | 6500 | IP20 | - | |
| 919515815273 | SP780 H LED18S-4000 PSD W5L112 OD WH | 1,800 lm | 15 W | 4000 | IP20 | - | |
| 919515815274 | SP780X H LED18S-6500 PSD W5L112 OD WH | 1,800 lm | 15 W | 6500 | IP20 | - | |
| 919515815275 | SP780X H LED18S-4000 PSD W5L112 OD WH | 1,800 lm | 15 W | 4000 | IP20 | - | |
| 919515815276 | SP780 H LED50S-6500 PSU W5L224 OD WH | 5,000 lm | 40 W | 6500 | IP20 | - | |
| 919515815280 | SP780 H LED44S-6500 PSU W5L224 OD WH | 4,400 lm | 36 W | 6500 | IP20 | - | |
| 919515815305 | SP780 H LED25S-5700 PSU W5L112 OD WH | 2,500 lm | 20 W | 5700 | IP20 | - | |
| 919515815306 | SP780 H LED23S-5700 PSU W5L112 OC WH | 2,300 lm | 20 W | 5700 | IP20 | - | |
| 919515815307 | SP780 H LED22S-5700 PSU W5L112 OD WH | 2,200 lm | 18 W | 5700 | IP20 | - | |
| 919515815308 | SP780X H LED22S-5700 PSU W5L112 OD WH | 2,200 lm | 18 W | 5700 | IP20 | - | |
| 919515815309 | SP780X H LED20S-5700 PSU W5L112 OC WH | 2,000 lm | 18 W | 5700 | IP20 | - | |
| 919515815310 | SP780 H LED18S-5700 PSU W5L112 OD WH | 1,800 lm | 15 W | 5700 | IP20 | - | |
| 919515815311 | SP780X H LED18S-5700 PSU W5L112 OD WH | 1,800 lm | 15 W | 5700 | IP20 | - | |
| 919515815312 | SP780 H LED25S-5700 PSD W5L112 OD WH | 2,500 lm | 20 W | 5700 | IP20 | - | |
| 919515815316 | SP780X H LED20S-5700 PSD W5L112 OC WH | 2,000 lm | 18 W | 5700 | IP20 | - | |
| 919515815899 | SP780 H LED25S-6500 PSU W5L112 OD S1 WH | 2,500 lm | 20 W | 6500 | IP20 | - |
919515815225
SP780 H LED25S-6500 PSU W5L112 OD WH
919515815226
SP780 H LED25S-4000 PSU W5L112 OD WH
919515815227
SP780 H LED23S-6500 PSU W5L112 OC WH
919515815228
SP780 H LED23S-4000 PSU W5L112 OC WH
919515815252
SP780 H LED22S-6500 PSU W5L112 OD WH
919515815253
SP780 H LED22S-4000 PSU W5L112 OD WH
919515815254
SP780X H LED22S-6500 PSU W5L112 OD WH
919515815255
SP780X H LED22S-4000 PSU W5L112 OD WH
919515815256
SP780X H LED20S-6500 PSU W5L112 OC WH
919515815257
SP780X H LED20S-4000 PSU W5L112 OC WH
919515815258
SP780 H LED18S-6500 PSU W5L112 OD WH
919515815259
SP780 H LED18S-4000 PSU W5L112 OD WH
919515815260
SP780X H LED18S-6500 PSU W5L112 OD WH
919515815261
SP780X H LED18S-4000 PSU W5L112 OD WH
919515815262
SP780 H LED25S-6500 PSD W5L112 OD WH
919515815263
SP780 H LED25S-4000 PSD W5L112 OD WH
919515815264
SP780 H LED23S-6500 PSD W5L112 OC WH
919515815265
SP780 H LED23S-4000 PSD W5L112 OC WH
919515815266
SP780 H LED22S-6500 PSD W5L112 OD WH
919515815267
SP780 H LED22S-4000 PSD W5L112 OD WH
919515815268
SP780X H LED22S-6500 PSD W5L112 OD WH
919515815269
SP780X H LED22S-4000 PSD W5L112 OD WH
919515815270
SP780X H LED20S-6500 PSD W5L112 OC WH
919515815271
SP780X H LED20S-4000 PSD W5L112 OC WH
919515815272
SP780 H LED18S-6500 PSD W5L112 OD WH
919515815273
SP780 H LED18S-4000 PSD W5L112 OD WH
919515815274
SP780X H LED18S-6500 PSD W5L112 OD WH
919515815275
SP780X H LED18S-4000 PSD W5L112 OD WH
919515815276
SP780 H LED50S-6500 PSU W5L224 OD WH
919515815280
SP780 H LED44S-6500 PSU W5L224 OD WH
919515815305
SP780 H LED25S-5700 PSU W5L112 OD WH
919515815306
SP780 H LED23S-5700 PSU W5L112 OC WH
919515815307
SP780 H LED22S-5700 PSU W5L112 OD WH
919515815308
SP780X H LED22S-5700 PSU W5L112 OD WH
919515815309
SP780X H LED20S-5700 PSU W5L112 OC WH
919515815310
SP780 H LED18S-5700 PSU W5L112 OD WH
919515815311
SP780X H LED18S-5700 PSU W5L112 OD WH
919515815312
SP780 H LED25S-5700 PSD W5L112 OD WH
919515815316
SP780X H LED20S-5700 PSD W5L112 OC WH
919515815899
SP780 H LED25S-6500 PSU W5L112 OD S1 WH
