Data and documents come from the official Signify (Philips) catalogue.
Industrial lightingOffice lightingWaterproof and cleanroom
Ledinaire waterproof
WT060C
The Ledinaire waterpprof (WT060) range contains a selection of popular off-the-shelf waterproof LED luminaires that comes with the high Philips quality levels at a competitive price
List the order codes — we prepare a quotation and check availability. · 12 order codes
Family specifications
Ranges across every order code of the family. The exact values of a specific order code are in the table below: the «Specifications» button in its row.
Light technical
Luminous flux (lm)
1,800–8,000 lm
Efficacy (lm/W)
120–125 lm/W
CCT (K)
4000 / 6500
Color rendering
80-89
Light distribution
Symmetrical
UGR value
26
Electrical and controls
Wattage (W)
15–65 W
Dimming controls
-
Mechanical and housing
Housing material
Polycarbonate
Color of Housing
Grey
IP rating
IP66
IK rating
IK08
Length (mm)
611–1,801 mm
Width (mm)
69 mm
Height (mm)
59 mm
The Ledinaire waterpprof (WT060) range contains a selection of popular off-the-shelf waterproof LED luminaires that comes with the high Philips quality levels at a competitive price. Reliable, energy efficient and affordable. Ledinaire enables, simple and quick installation, with optional through wiring possibility.
Features
Robust (IK08) and waterproof (IP66) luminaire
Multiple lengths and light levels available
Mounting bracket can be positioned over full length of luminaire
Benefits
Philips quality and reliability
Energy saving
Diffuse comfortable light
Easy installation, through external push in connector
