Public spacesArchitectural floodlighting
UniFlood M G2
BVP353 / BVP354 / BVP355
Philips UniFlood M gen2 is a cost-effective, exterior-rated architectural LED floodlight that’s designed for façade, landscape and outdoor flood lighting applications
List the order codes — we prepare a quotation and check availability. · 504 order codes
Family specifications
Ranges across every order code of the family. The exact values of a specific order code are in the table below: the «Specifications» button in its row.
Light technical
Luminous flux (lm)
960–43,215 lm
Efficacy (lm/W)
38–116 lm/W
CCT (K)
2700 / 3000 / 4000 / -
Color rendering
80-89
Optical cover
Clear glass
Electrical and controls
Wattage (W)
24–450 W
Dimming controls
- / Dynamic DMX/RDM
Mechanical and housing
Housing material
Aluminum extruded
Color of Housing
Grey
IP rating
IP66
IK rating
IK06
Length (mm)
155–569 mm
Width (mm)
140–478 mm
Height (mm)
149–231 mm
Philips UniFlood M gen2 is a cost-effective, exterior-rated architectural LED floodlight that’s designed for façade, landscape and outdoor flood lighting applications. The robust, modular, rectangular design features highly-efficient optics, making it ideal for illuminating everything from multi-storey façades and bridges to landmarks and monuments. This LED floodlight is available in white, monochromatic colors, RGB, RGBW and tunable white. It comes with six different spread lenses ranging from narrow spot to wide flood and has DMX512/RDM control option. A truly modular floodlight that gives architects and designers the freedom to explore a wide range of concepts and designs with no limitations.
Features
Standard: RGBW, RGB, 2700K, 3000K and 4000K
Optional 5000K, monochromatic colors and tunable white
Flexible lengths from 155 to 569 mm
Adjustable tilting angles for each head and for the whole set
Steel brackets
Safety and installation: For outdoor use only.
Benefits
Great design flexibility with individually tilting heads and controls
Create the right lighting effect with six different spread lenses (narrow spot to wide flood)
