Ideal for applications requiring high lumen packages, RoadFlex was designed to comply with the highest road lighting standards.
Data and documents come from the official Signify (Philips) catalogue.
BRP492 / BRP493
Ideal for applications requiring high lumen packages, RoadFlex was designed to comply with the highest road lighting standards.
List the order codes — we prepare a quotation and check availability. · 16 order codes
Ideal for applications requiring high lumen packages, RoadFlex was designed to comply with the highest road lighting standards.
Every version of the family from the official catalogue. Click PDF to download the datasheet of a specific order code.
| Order code | Name | Luminous flux | Wattage | CCT | IP | Optic | |
|---|---|---|---|---|---|---|---|
| 919306031272 | BRP492 A LED221-4S/NW 170W DW1 P7 0-10 RoadFlex, 21600 lm, 170 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 21,600 lm | 170 W | 4000 | IP66 | — | |
| 919306031273 | BRP492 A LED247-4S/NW 190W DW1 P7 0-10 RoadFlex, 23800 lm, 190 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 23,800 lm | 190 W | 4000 | IP66 | — | |
| 919306031274 | BRP492 A LED273-4S/NW 210W DW1 P7 0-10 RoadFlex, 25700 lm, 210 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 25,700 lm | 210 W | 4000 | IP66 | — | |
| 919306031275 | BRP493 A LED299-4S/NW 230W DW1 P7 0-10 RoadFlex, 29100 lm, 230 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 29,100 lm | 230 W | 4000 | IP66 | — | |
| 919306031276 | BRP493 A LED325-4S/NW 250W DW1 P7 0-10 RoadFlex, 31400 lm, 250 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 31,400 lm | 250 W | 4000 | IP66 | — | |
| 919306031277 | BRP493 A LED351-4S/NW 270W DW1 P7 0-10 RoadFlex, 33500 lm, 270 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 33,500 lm | 270 W | 4000 | IP66 | — | |
| 919306031278 | BRP492 A LED195-4S/CW 150W DW1 P7 0-10 RoadFlex, 19400 lm, 150 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 19,400 lm | 150 W | 5000 | IP66 | — | |
| 919306031279 | BRP492 A LED221-4S/CW 170W DW1 P7 0-10 RoadFlex, 21600 lm, 170 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 21,600 lm | 170 W | 5000 | IP66 | — | |
| 919306031281 | BRP492 A LED247-4S/CW 190W DW1 P7 0-10 RoadFlex, 23800 lm, 190 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 23,800 lm | 190 W | 5000 | IP66 | — | |
| 919306031282 | BRP492 A LED273-4S/CW 210W DW1 P7 0-10 RoadFlex, 25700 lm, 210 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 25,700 lm | 210 W | 5000 | IP66 | — | |
| 919306031283 | BRP493 A LED299-4S/CW 230W DW1 P7 0-10 RoadFlex, 29100 lm, 230 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 29,100 lm | 230 W | 5000 | IP66 | — | |
| 919306031284 | BRP493 A LED325-4S/CW 250W DW1 P7 0-10 RoadFlex, 31400 lm, 250 W, 140° x 70°, Safety class I, Side-entry for diameter 48 to 60 mm | 31,400 lm | 250 W | 5000 | IP66 | — | |
| 919306031891 | BRP492 LED238-6S/NW 154W DW1 P7 0-10 RoadFlex, 23800 lm, 154 W, 140° x 70°, Analog, Safety class I, Side-entry for diameter 48 to 60 mm | 23,800 lm | 154 W | 4000 | IP65 | — | |
| 919306031911 | BRP492 LED281-6S/NW 187W DW1 P7 0-10 RoadFlex, 28100 lm, 187 W, 140° x 70°, Analog, Safety class I, Side-entry for diameter 48 to 60 mm | 28,100 lm | 187 W | 4000 | IP65 | — | |
| 919306031931 | BRP493 LED301-6S/NW 194W DW1 P7 0-10 RoadFlex, 30100 lm, 194 W, 140° x 70°, Analog, Safety class I, Side-entry for diameter 48 to 60 mm | 30,100 lm | 194 W | 4000 | IP65 | — | |
| 919306031951 | BRP493 LED335-6S/NW 220W DW1 P7 0-10 RoadFlex, 33500 lm, 220 W, 140° x 70°, Analog, Safety class I, Side-entry for diameter 48 to 60 mm | 33,500 lm | 220 W | 4000 | IP65 | — |
919306031272
BRP492 A LED221-4S/NW 170W DW1 P7 0-10
919306031273
BRP492 A LED247-4S/NW 190W DW1 P7 0-10
919306031274
BRP492 A LED273-4S/NW 210W DW1 P7 0-10
919306031275
BRP493 A LED299-4S/NW 230W DW1 P7 0-10
919306031276
BRP493 A LED325-4S/NW 250W DW1 P7 0-10
919306031277
BRP493 A LED351-4S/NW 270W DW1 P7 0-10
919306031278
BRP492 A LED195-4S/CW 150W DW1 P7 0-10
919306031279
BRP492 A LED221-4S/CW 170W DW1 P7 0-10
919306031281
BRP492 A LED247-4S/CW 190W DW1 P7 0-10
919306031282
BRP492 A LED273-4S/CW 210W DW1 P7 0-10
919306031283
BRP493 A LED299-4S/CW 230W DW1 P7 0-10
919306031284
BRP493 A LED325-4S/CW 250W DW1 P7 0-10
919306031891
BRP492 LED238-6S/NW 154W DW1 P7 0-10
919306031911
BRP492 LED281-6S/NW 187W DW1 P7 0-10
919306031931
BRP493 LED301-6S/NW 194W DW1 P7 0-10
919306031951
BRP493 LED335-6S/NW 220W DW1 P7 0-10
Engineering-first approach: we start with your site’s requirements, not with equipment. Leave your contacts — we’ll prepare a lighting calculation.
