BRP482 / BRP481 / BRP483
With an extremely high measured efficacy of up to 190 lm/W, excellent optical gear and great installation flexibility with an integrated angle adjustment system, the RoadForce family ensures a high-quality luminous result compliant with local application standards
List the order codes — we prepare a quotation and check availability. · 104 order codes
With an extremely high measured efficacy of up to 190 lm/W, excellent optical gear and great installation flexibility with an integrated angle adjustment system, the RoadForce family ensures a high-quality luminous result compliant with local application standards. Designed with robust components, the RoadForce luminaire complies with the highest quality standards while reducing the maintenance costs.
Every version of the family from the official catalogue. Click PDF to download the datasheet of a specific order code.
| Order code | Name | Luminous flux | Wattage | CCT | IP | Optic | |
|---|---|---|---|---|---|---|---|
| 820619285181 | BRP482 LED160-2S NW 92W DML P7 0-10 MX4 RoadForce, 16000 lm, 92 W, Analog, Safety class I, Mounting bracket adjustable | 16,000 lm | 92 W | 4000 | IP66 | — | |
| 919306031981 | BRP481 LED51 NW 27W DWL P7 0-10 RoadForce, 5100 lm, 27.81 W, Analog, Safety class I, Mounting bracket adjustable | 5,100 lm | 27.81 W | 4000 | IP66 | — | |
| 919306031991 | BRP481 LED60 NW 33W DWL P7 0-10 RoadForce, 6100 lm, 33.73 W, Analog, Safety class I, Mounting bracket adjustable | 6,100 lm | 33.73 W | 4000 | IP66 | — | |
| 919306032011 | BRP481 LED85 NW 48W DWL P7 0-10 RoadForce, 8500 lm, 48.99 W, Analog, Safety class I, Mounting bracket adjustable | 8,500 lm | 48.99 W | 4000 | IP66 | — | |
| 919306032061 | BRP481 LED73 CW 41W DWL P7 0-10 RoadForce, 7300 lm, 41.57 W, Analog, Safety class I, Mounting bracket adjustable | 7,300 lm | 41.57 W | 5000 | IP66 | — | |
| 919306032091 | BRP481 LED43 NW 24W DML P7 0-10 RoadForce, 4500 lm, 25.36 W, Analog, Safety class I, Mounting bracket adjustable | 4,500 lm | 25.36 W | 4000 | IP66 | — | |
| 919306032101 | BRP481 LED51 NW 27W DML P7 0-10 RoadForce, 5100 lm, 27.81 W, Analog, Safety class I, Mounting bracket adjustable | 5,100 lm | 27.81 W | 4000 | IP66 | — | |
| 919306032111 | BRP481 LED60 NW 33W DML P7 0-10 RoadForce, 6100 lm, 33.73 W, Analog, Safety class I, Mounting bracket adjustable | 6,100 lm | 33.73 W | 4000 | IP66 | — | |
| 919306032121 | BRP481 LED73 NW 41W DML P7 0-10 RoadForce, 7300 lm, 41.57 W, Analog, Safety class I, Mounting bracket adjustable | 7,300 lm | 41.57 W | 4000 | IP66 | — | |
| 919306032131 | BRP481 LED85 NW 48W DML P7 0-10 RoadForce, 8500 lm, 48.99 W, Analog, Safety class I, Mounting bracket adjustable | 8,500 lm | 48.99 W | 4000 | IP66 | — | |
| 919306032141 | BRP481 LED96 NW 55W DML P7 0-10 RoadForce, 9600 lm, 56.37 W, Analog, Safety class I, Mounting bracket adjustable | 9,600 lm | 56.37 W | 4000 | IP66 | — | |
| 919306032321 | BRP482 LED126 CW 70W DWL P7 0-10 RoadForce, 12600 lm, 68.97 W, Analog, Safety class I, Mounting bracket adjustable | 12,600 lm | 68.97 W | 5000 | IP66 | — | |
| 919306032391 | BRP482 LED104 NW 56W DML P7 0-10 RoadForce, 10400 lm, 55.88 W, Analog, Safety class I, Mounting bracket adjustable | 10,400 lm | 55.88 W | 4000 | IP66 | — | |
| 919306032401 | BRP482 LED113 NW 61W DML P7 0-10 RoadForce, 11300 lm, 60.74 W, Analog, Safety class I, Mounting bracket adjustable | 11,300 lm | 60.74 W | 4000 | IP66 | — | |
| 919306032421 | BRP482 LED136 NW 76W DML P7 0-10 RoadForce, 13600 lm, 75.28 W, Analog, Safety class I, Mounting bracket adjustable | 13,600 lm | 75.28 W | 4000 | IP66 | — | |
| 919306032431 | BRP482 LED147 NW 83W DML P7 0-10 RoadForce, 14700 lm, 82.77 W, Analog, Safety class I, Mounting bracket adjustable | 14,700 lm | 82.77 W | 4000 | IP66 | — | |
| 919306032441 | BRP482 LED160 NW 92W DML P7 0-10 RoadForce, 16000 lm, 91.3 W, Analog, Safety class I, Mounting bracket adjustable | 16,000 lm | 91.3 W | 4000 | IP66 | — | |
| 919306032451 | BRP482 LED172 NW 100W DML P7 0-10 RoadForce, 17200 lm, 99.99 W, Analog, Safety class I, Mounting bracket adjustable | 17,200 lm | 99.99 W | 4000 | IP66 | — | |
| 919306032461 | BRP482 LED179 NW 105W DML P7 0-10 RoadForce, 17900 lm, 105.44 W, Analog, Safety class I, Mounting bracket adjustable | 17,900 lm | 105.44 W | 4000 | IP66 | — | |
| 919306032471 | BRP482 LED186 NW 110W DML P7 0-10 RoadForce, 18600 lm, 110.75 W, Analog, Safety class I, Mounting bracket adjustable | 18,600 lm | 110.75 W | 4000 | IP66 | — | |
| 919306032631 | BRP483 LED216 NW 122W DML P7 0-10 RoadForce, 21600 lm, 120.96 W, Analog, Safety class I, Mounting bracket adjustable | 21,600 lm | 120.96 W | 4000 | IP66 | — | |
| 919306032651 | BRP483 LED255 NW 150W DML P7 0-10 RoadForce, 25500 lm, 148.46 W, Analog, Safety class I, Mounting bracket adjustable | 25,500 lm | 148.46 W | 4000 | IP66 | — | |
| 919306032751 | BRP483 LED255 CW 150W DML P7 0-10 RoadForce, 25500 lm, 148.46 W, Analog, Safety class I, Mounting bracket adjustable | 25,500 lm | 148.46 W | 5000 | IP66 | — | |
| 919306032791 | BRP484 LED292 NW 169W DML P7 0-10 RoadForce, 29200 lm, 166.56 W, Analog, Safety class I, Mounting bracket adjustable | 29,200 lm | 166.56 W | 4000 | IP66 | — | |
| 919306032811 | BRP484 LED292 CW 169W DWL P7 0-10 RoadForce, 29200 lm, 166.56 W, Analog, Safety class I, Mounting bracket adjustable | 29,200 lm | 166.56 W | 5000 | IP66 | — | |
| 919306032841 | BRP484 LED307 CW 179W DML P7 0-10 RoadForce, 30700 lm, 176.68 W, Analog, Safety class I, Mounting bracket adjustable | 30,700 lm | 176.68 W | 5000 | IP66 | — | |
| 919306032891 | BRP486 LED351 NW 195W DWL P7 0-10 RoadForce, 35100 lm, 190.25 W, Analog, Safety class I, Mounting bracket adjustable | 35,100 lm | 190.25 W | 4000 | IP66 | — | |
| 919306032901 | BRP486 LED351 NW 195W DML P7 0-10 RoadForce, 35100 lm, 190.25 W, Analog, Safety class I, Mounting bracket adjustable | 35,100 lm | 190.25 W | 4000 | IP66 | — | |
| 919306032921 | BRP486 LED351 CW 195W DML P7 0-10 RoadForce, 35100 lm, 190.25 W, Analog, Safety class I, Mounting bracket adjustable | 35,100 lm | 190.25 W | 5000 | IP66 | — | |
| 919306034141 | BRP481 LED43-2S NW 24W DWL P7 0-10 RoadForce, 4300 lm, 24 W, Analog, Safety class I, Mounting bracket adjustable | 4,300 lm | 24 W | 4000 | IP66 | — | |
| 919306034591 | BRP482 LED126-2S NW 70W DML P7 0-10 RoadForce, 12600 lm, 70 W, Analog, Safety class I, Mounting bracket adjustable | 12,600 lm | 70 W | 4000 | IP66 | — | |
| 919306034601 | BRP482 LED126-2S NW 70W DML P7 0-10 M RoadForce, 12600 lm, 70 W, Analog, Safety class I, Mounting bracket adjustable | 12,600 lm | 70 W | 4000 | IP66 | — | |
| 919306034611 | BRP482 LED126-2S NW 70W DWL P7 0-10 RoadForce, 12600 lm, 70 W, Analog, Safety class I, Mounting bracket adjustable | 12,600 lm | 70 W | 4000 | IP66 | — | |
| 919306034621 | BRP482 LED126-2S NW 70W DWL P7 0-10 M RoadForce, 12600 lm, 70 W, Analog, Safety class I, Mounting bracket adjustable | 12,600 lm | 70 W | 4000 | IP66 | — | |
| 919306034651 | BRP482 LED136-2S NW 76W DML P7 0-10 RoadForce, 13600 lm, 76 W, Analog, Safety class I, Mounting bracket adjustable | 13,600 lm | 76 W | 4000 | IP66 | — | |
| 919306034661 | BRP482 LED136-2S NW 76W DML P7 0-10 M RoadForce, 13600 lm, 76 W, Analog, Safety class I, Mounting bracket adjustable | 13,600 lm | 76 W | 4000 | IP66 | — | |
| 919306034671 | BRP482 LED136-2S NW 76W DWL P7 0-10 RoadForce, 13600 lm, 76 W, Analog, Safety class I, Mounting bracket adjustable | 13,600 lm | 76 W | 4000 | IP66 | — | |
| 919306034681 | BRP482 LED136-2S NW 76W DWL P7 0-10 M RoadForce, 13600 lm, 76 W, Analog, Safety class I, Mounting bracket adjustable | 13,600 lm | 76 W | 4000 | IP66 | — | |
| 919306034711 | BRP482 LED147-2S NW 83W DML P7 0-10 RoadForce, 14700 lm, 83 W, Analog, Safety class I, Mounting bracket adjustable | 14,700 lm | 83 W | 4000 | IP66 | — | |
| 919306034721 | BRP482 LED147-2S NW 83W DML P7 0-10 M RoadForce, 14700 lm, 83 W, Analog, Safety class I, Mounting bracket adjustable | 14,700 lm | 83 W | 4000 | IP66 | — |
820619285181
BRP482 LED160-2S NW 92W DML P7 0-10 MX4
919306031981
BRP481 LED51 NW 27W DWL P7 0-10
919306031991
BRP481 LED60 NW 33W DWL P7 0-10
919306032011
BRP481 LED85 NW 48W DWL P7 0-10
919306032061
BRP481 LED73 CW 41W DWL P7 0-10
919306032091
BRP481 LED43 NW 24W DML P7 0-10
919306032101
BRP481 LED51 NW 27W DML P7 0-10
919306032111
BRP481 LED60 NW 33W DML P7 0-10
919306032121
BRP481 LED73 NW 41W DML P7 0-10
919306032131
BRP481 LED85 NW 48W DML P7 0-10
919306032141
BRP481 LED96 NW 55W DML P7 0-10
919306032321
BRP482 LED126 CW 70W DWL P7 0-10
919306032391
BRP482 LED104 NW 56W DML P7 0-10
919306032401
BRP482 LED113 NW 61W DML P7 0-10
919306032421
BRP482 LED136 NW 76W DML P7 0-10
919306032431
BRP482 LED147 NW 83W DML P7 0-10
919306032441
BRP482 LED160 NW 92W DML P7 0-10
919306032451
BRP482 LED172 NW 100W DML P7 0-10
919306032461
BRP482 LED179 NW 105W DML P7 0-10
919306032471
BRP482 LED186 NW 110W DML P7 0-10
919306032631
BRP483 LED216 NW 122W DML P7 0-10
919306032651
BRP483 LED255 NW 150W DML P7 0-10
919306032751
BRP483 LED255 CW 150W DML P7 0-10
919306032791
BRP484 LED292 NW 169W DML P7 0-10
919306032811
BRP484 LED292 CW 169W DWL P7 0-10
919306032841
BRP484 LED307 CW 179W DML P7 0-10
919306032891
BRP486 LED351 NW 195W DWL P7 0-10
919306032901
BRP486 LED351 NW 195W DML P7 0-10
919306032921
BRP486 LED351 CW 195W DML P7 0-10
919306034141
BRP481 LED43-2S NW 24W DWL P7 0-10
919306034591
BRP482 LED126-2S NW 70W DML P7 0-10
919306034601
BRP482 LED126-2S NW 70W DML P7 0-10 M
919306034611
BRP482 LED126-2S NW 70W DWL P7 0-10
919306034621
BRP482 LED126-2S NW 70W DWL P7 0-10 M
919306034651
BRP482 LED136-2S NW 76W DML P7 0-10
919306034661
BRP482 LED136-2S NW 76W DML P7 0-10 M
919306034671
BRP482 LED136-2S NW 76W DWL P7 0-10
919306034681
BRP482 LED136-2S NW 76W DWL P7 0-10 M
919306034711
BRP482 LED147-2S NW 83W DML P7 0-10
919306034721
BRP482 LED147-2S NW 83W DML P7 0-10 M
