Данные и документация — из официального каталога Signify (Philips).

Офисное освещениеОбщественные пространстваИзлучающие вниз светильники для акцентного освещения

GreenSpace Evo Mini Fixed

Name: Philips Lighting Узбекистан
Address: г. Ташкент, Чиланзарский р-н, Лутфий МФЙ, ул. Богистон, 10, Tashkent, UZ
Telephone: +998 90 945 1117
Price range: $$

RS320B

GreenSpace Evo Mini Fixed is a miniaturized accent spot with a subtle and neutral design

Световой поток (лм): 700–2 300 лм
Мощность (Вт): 6,8–17,7 Вт
Эффективность (лм/Вт): 94–134 лм/Вт
CCT (K): 3000 / 4000
Степень защиты IP: IP20 / IP20/54
Класс IK: IK02

Запросить предложение Техническое описание семейства (PDF)

Укажите артикулы — подготовим коммерческое предложение и проверим наличие. · 15 артикулов

Описание доступно на английском — русская версия готовится.

GreenSpace Evo Mini Fixed is a miniaturized accent spot with a subtle and neutral design. This makes the product an ideal choice for fashion, hospitality and residential applications. The 3D printed housing is crafted from at least 65% recycled or bio-circular materials, while the heatsink is made from 85% recycled aluminium. Because of its circular design, the luminaire is upgradable, reusable, fully serviceable and recyclable. Combined with the high energy efficiency, this makes the GreenSpace Evo Mini Fixed a sustainable choice for accent lighting. The PerfectAccent deep reflectors ensure a light effect with increased sparkle and improved shopper eye comfort. Renovation projects are easy with Perfect Fit due to the multiple cutout dimensions that are available. Further customization of colors, textures and Perfect Fit cutouts is possible via Philips MyCreation

Особенности

Easy access to the optics, LED and front glass
Serviceable and upgradeable with standard tools
Available in multiple Perfect Fit cutout dimensions (80mm-100mm)
Reduced carbon footprint due to high efficacy
Equipped with state-of-the-art PerfectAccent deep reflectors
Connectivity options: Interact compatible DALI (DIA) and Wireless (WIA)
Optional front glass (recommended for dusty environments)

Безопасность и монтаж: Cleaning of the optic should only be done with pressurized air. Touching the LED or reflector is forbidden. For food preparation areas and areas with high levels of dust, the use of the optional front glass is strongly advised, as it can be cleaned with a (dry) microfiber clothDuring maintenance, the product must be switched off and cooled downThe product must be installed out of arm’s reach. Manipulating the product when hot is only possible with an insulated glove

Преимущества

Blends into stores with a clean and neutral design
Retrofitting older installations is easy with Perfect Fit’s multiple available cutout options
More sparkle and enhanced shopper eye comfort with PerfectAccent deep reflectors
Extend the useful life of the product with easy serviceability and upgradeability
The recycled materials and high energy efficiency help further reduce the carbon footprint of the product

Применение

Fashion
Hospitality
Residential

Документация

Техническое описание семейства (PDF) · EN
Техническое описание артикула — PDF ↓

Модификации и артикулы

Все варианты семейства из официального каталога. Нажмите PDF, чтобы скачать техническое описание конкретного артикула.

Код заказа	Наименование	Световой поток	Мощность	Цветность	IP	Оптика	PDF
910505102988	RS320B 12S/830 PSU-E HWB WH GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 8.6 W, D79 mm, 1150 lm, 3000 K, High-reflective metal reflector Medium beam 20 to 40 degrees, White, IP20/54	1,150 лм	8.6 Вт	3000	IP20/54	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505102989	RS320B 12S/PW930 PSU-E HMB FG WH GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 8.6 W, D79 mm, 1230 lm, PremiumWhite, 3000 K, CRI>90, High-reflective metal reflector Medium beam 20 to 40 degrees, White, IP20/54	1,230 лм	8.6 Вт	3000	IP20/54	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505102990	RS320B 12S/PC930 WIA-E HMB BK GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 10.3 W, D79 mm, 1250 lm, PremiumColor, 3000 K, CRI>90, Wireless, Interact Ready, High-reflective metal reflector Medium beam 20 to 40 degrees, PerfectAccent High-Efficacy reflector, Black, IP20	1,250 лм	10.3 Вт	3000	IP20	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505102991	RS320B 17S/840 PSU-E HMB BK GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 12 W, D79 mm, 1850 lm, 4000 K, High-reflective metal reflector Medium beam 20 to 40 degrees, PerfectAccent High-Efficacy reflector, Black, IP20/54	1,850 лм	12 Вт	4000	IP20/54	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505102992	RS320B 17S/PW940 DIA-E HWB FG GR GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 12.1 W, D79 mm, 1600 lm, PremiumWhite, 4000 K, CRI>90, DALI, Interact Ready, High-reflective metal reflector Medium beam 20 to 40 degrees, PerfectAccent High-Efficacy reflector, Gray, IP20/54	1,600 лм	12.1 Вт	4000	IP20/54	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505102993	RS320B 17S/PC930 WIA-E HMB WH GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 17.7 W, D79 mm, 1970 lm, PremiumColor, 3000 K, CRI>90, Wireless, Interact Ready, High-reflective metal reflector Medium beam 20 to 40 degrees, PerfectAccent High-Efficacy reflector, White, IP20	1,970 лм	17.7 Вт	3000	IP20	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505102994	RS320B 20S/830 PSU-E HWB BK GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 16 W, D79 mm, 2180 lm, 3000 K, High-reflective metal reflector Medium beam 20 to 40 degrees, PerfectAccent High-Efficacy reflector, Black, IP20	2,180 лм	16 Вт	3000	IP20	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505102995	RS320B 20S/PW930 WIA-E HMB WH GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 15.8 W, D79 mm, 2160 lm, PremiumWhite, 3000 K, CRI>90, Wireless, Interact Ready, High-reflective metal reflector Medium beam 20 to 40 degrees, PerfectAccent High-Efficacy reflector, White, IP20	2,160 лм	15.8 Вт	3000	IP20	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505102996	RS320B 20S/PW940 DIA-E HMB WH GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 16 W, D79 mm, 2300 lm, PremiumWhite, 4000 K, CRI>90, DALI, Interact Ready, High-reflective metal reflector Medium beam 20 to 40 degrees, PerfectAccent High-Efficacy reflector, White, IP20	2,300 лм	16 Вт	4000	IP20	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505102997	RS320B 12S/PW940 PSU-E HNB FG GR GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 10.7 W, D79 mm, 1250 lm, PremiumWhite, 4000 K, CRI>90, High-reflective metal reflector Narrow beam 10 to 20 degrees, Gray, IP20/54	1,250 лм	10.7 Вт	4000	IP20/54	High-reflective metal reflector Narrow beam 10 to 20 degrees	PDF
910505104579	RS320B 7S/830 PSU-E HWB WH GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 6.8 W, D79 mm, 790 lm, 3000 K, High-reflective metal reflector Medium beam 20 to 40 degrees, White, IP20	790 лм	6.8 Вт	3000	IP20	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505104580	RS320B 7S/840 PSU-E HVWB WH GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 6.8 W, D79 mm, 900 lm, 4000 K, High-reflective metal reflector Wide beam 40 to 80 degrees, White, IP20	900 лм	6.8 Вт	4000	IP20	High-reflective metal reflector Wide beam 40 to 80 degrees	PDF
910505104581	RS320B 7S/PW930 PSU-E HWB BK GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 6.8 W, D79 mm, 790 lm, PremiumWhite, 3000 K, CRI>90, High-reflective metal reflector Medium beam 20 to 40 degrees, Black, IP20	790 лм	6.8 Вт	3000	IP20	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505104582	RS320B 7S/PW940 PSU-E HWB BK GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 6.8 W, D79 mm, 850 lm, PremiumWhite, 4000 K, CRI>90, High-reflective metal reflector Medium beam 20 to 40 degrees, Black, IP20/54	850 лм	6.8 Вт	4000	IP20/54	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF
910505104583	RS320B 7S/PC930 PSU-E HMB FG BK GreenSpace Evo Mini Fixed, Recessed accent, 3D printed, 7.3 W, D79 mm, 700 lm, PremiumColor, 3000 K, CRI>90, High-reflective metal reflector Medium beam 20 to 40 degrees, Black, IP20/54	700 лм	7.3 Вт	3000	IP20/54	High-reflective metal reflector Medium beam 20 to 40 degrees	PDF

910505102988
RS320B 12S/830 PSU-E HWB WH
PDF
Световой поток
1,150 лм
Мощность
8.6 Вт
Цветность
3000
IP
IP20/54
910505102989
RS320B 12S/PW930 PSU-E HMB FG WH
PDF
Световой поток
1,230 лм
Мощность
8.6 Вт
Цветность
3000
IP
IP20/54
910505102990
RS320B 12S/PC930 WIA-E HMB BK
PDF
Световой поток
1,250 лм
Мощность
10.3 Вт
Цветность
3000
IP
IP20
910505102991
RS320B 17S/840 PSU-E HMB BK
PDF
Световой поток
1,850 лм
Мощность
12 Вт
Цветность
4000
IP
IP20/54
910505102992
RS320B 17S/PW940 DIA-E HWB FG GR
PDF
Световой поток
1,600 лм
Мощность
12.1 Вт
Цветность
4000
IP
IP20/54
910505102993
RS320B 17S/PC930 WIA-E HMB WH
PDF
Световой поток
1,970 лм
Мощность
17.7 Вт
Цветность
3000
IP
IP20
910505102994
RS320B 20S/830 PSU-E HWB BK
PDF
Световой поток
2,180 лм
Мощность
16 Вт
Цветность
3000
IP
IP20
910505102995
RS320B 20S/PW930 WIA-E HMB WH
PDF
Световой поток
2,160 лм
Мощность
15.8 Вт
Цветность
3000
IP
IP20
910505102996
RS320B 20S/PW940 DIA-E HMB WH
PDF
Световой поток
2,300 лм
Мощность
16 Вт
Цветность
4000
IP
IP20
910505102997
RS320B 12S/PW940 PSU-E HNB FG GR
PDF
Световой поток
1,250 лм
Мощность
10.7 Вт
Цветность
4000
IP
IP20/54
910505104579
RS320B 7S/830 PSU-E HWB WH
PDF
Световой поток
790 лм
Мощность
6.8 Вт
Цветность
3000
IP
IP20
910505104580
RS320B 7S/840 PSU-E HVWB WH
PDF
Световой поток
900 лм
Мощность
6.8 Вт
Цветность
4000
IP
IP20
910505104581
RS320B 7S/PW930 PSU-E HWB BK
PDF
Световой поток
790 лм
Мощность
6.8 Вт
Цветность
3000
IP
IP20
910505104582
RS320B 7S/PW940 PSU-E HWB BK
PDF
Световой поток
850 лм
Мощность
6.8 Вт
Цветность
4000
IP
IP20/54
910505104583
RS320B 7S/PC930 PSU-E HMB FG BK
PDF
Световой поток
700 лм
Мощность
7.3 Вт
Цветность
3000
IP
IP20/54

Показано 15 из 15
