Sports lightingOffice lightingRecessed
DaySpace
RC740B / SP740B
For the modern workspace lighting challenges that may inspire exciting new concepts or rejuvenate routine patterns, DaySpace offers a distinctive approach with the emphasis on the overall integrated look of the ceiling rather than on the luminaire itself
List the order codes — we prepare a quotation and check availability. · 24 order codes
Family specifications
Ranges across every order code of the family. The exact values of a specific order code are in the table below: the «Specifications» button in its row.
Light technical
Luminous flux (lm)
2,800–3,800 lm
Efficacy (lm/W)
90 lm/W
CCT (K)
4000 / 5700 / 6500
Color rendering
80-89
Light distribution
Very wide beam angle 120°
Optical cover
UV stabilized Polycarbonate cover
Electrical and controls
Wattage (W)
30–44 W
Dimming controls
DALI / -
Mechanical and housing
Mounting type
Recessed mounting box square
Housing material
Steel
Color of Housing
White
IP rating
IP20
IK rating
IK02
For the modern workspace lighting challenges that may inspire exciting new concepts or rejuvenate routine patterns, DaySpace offers a distinctive approach with the emphasis on the overall integrated look of the ceiling rather than on the luminaire itself. DaySpace discreetly integrates into the ceiling to deliver soft and ethereal yet brilliant environments. A luminous web or well-defined squares perched for a geometric yet whimsical space – DaySpace comes to your design rescue. For the Architects, Designers & Real Estate Professionals Designing/ Developing Next Gen Office Spaces DaySpace Provides. Creative Freedom to Blend in Lighting as an Architectural Element of the office. The opportunity to create the desired ambience through its customizable nature. To Declutter and break away from the Boring 2’x2’ Lighting. Because of its unique design that minimizes the intrusion of the lighting surface into the office architecture and create a completely customized ambience
Features
Intelligent inner edge light
Seamless Joints
Single Piece molded PC Diffuser
Available in 2500/3000/3600lm with 4000/5700/6500K CCT
THD 0.9 5 & Class B serviceability
Recessed/ Suspended versions
Lifeclass of 50k hrs. @ 45⁰C ambient
Fixed output/ DALI
Safety and installation: Meant for Indoor Application Only. Should not be used in outdoor environment.
Benefits
An artificial skylight that delivers excellent light quality, to bring you close to natural light
Use of standard ceiling tile over the luminaire maintains visual consistency on the ceiling & better acoustics
Customization of back plate provides flexibility to match with office ambience
Volumetric illumination with natural Skylight effect
More Vertical Lux and ensures low glare
Clutter Free Ceiling and one can hide other services with this installation
